Ashok Leyland 100 kVA diesel genset
Ashok Leyland

100 kVA Diesel Genset

100kVA prime
Prime power
CPCB norms compliant
Engine model
AL6DTI G1, 122.0 HP, Turbocharged Intercooled, electronic A1 governing
Alternator
Brushless, Single Bearing, IP23, Class H Insulated, +/-0.5% voltage regulation, 0.8PF Lag, 50Hz
Cylinders
6 - 104x113mm bore x stroke, 5700cc, 17.5:1 CR
Cooling
Water-cooled (radiator)
Fuel tank capacity
200 L
Runtime @ 75% load
Dimensions (L×W×H)
3300 × 1250 × 1530 mm
Dry weight
1,874 kg
Enclosure
Weatherproof acoustic canopy (brochure dimensions are inclusive of canopy)
Emission norm
CPCB norms
Control panel
Optional AMF control panel (AL 4522 or DSE 6020 controller)
Warranty
2 years (entire package)

Indicative price range: 7.3L – ₹8.0L

Download official spec sheet (PDF) ↓

Specifications per Ashok Leyland LEYPOWER's official "LP10-160 kVA" Diesel Generating Set Specification brochure. Verified via a 300dpi table re-render and bore x stroke x cylinder-count vs. stated displacement cross-check (2.088L/4.009L/5.7L engine families all matched). States Prime ratings only -- no separate Standby column. Several ratings (10/15, 35/40, 50/63, 140/160 kVA) share one physical canopy/engine shell as twin catalog SKUs rather than a Prime/Standby duty pair for a single product; each is modeled as its own row carrying only its own stated output figures. This row previously carried placeholder/estimated specs (generic engine_model text and a fabricated +10% kva_standby); both are replaced here with real brochure data, and kva_standby is left null since the brochure states no Standby rating for this model. Product photo is the brochure's cover hero shot of a LEYPOWER canopy unit, not confirmed to be this exact kVA rating's physical size. Brochure only states general CPCB-norms compliance, not a specific tier such as CPCB IV+ -- confirm current status with an authorized dealer before purchase.
